| Specifications | ||
|
|
|
|
|
Model Nunber |
ZJV9402TJZG/ZJV9404TJZG/ |
|
|
Tare Weight |
About5.9T |
|
|
Dimension |
12500mm*2500mm*1575mm |
|
|
Loading Capacity |
45T |
|
|
Axle |
13 T/16T,FUWA/BPW/Huajing Brand |
|
|
Rim |
9.00-22.5 12pieces |
|
|
Tire |
12.00R22.5/315 80R22.5 12pieces |
|
|
Suspension |
Mechanical suspension (Germany Type or America Type) or Air suspension(China brand or BPW brand) |
|
|
Spring leaf |
90(W)mm*13(Thickness)mm*10 Layer (especial for exporting market ) |
|
|
King pin |
JOST brand 2.0 or 3.5 inch bolts type or Welding type |
|
|
Support leg |
JOST brand D200T or China brand 28Tons (Double speed) |
|
|
Main beam |
Height: 500mm, upper plate is 14mm, middle plate is 8mm, Down plate is 16mm; Material is Q345B Steel. |
|
|
Side beam |
16mm channel steel (Material is Q235steel). |
|
|
Bottom platform |
3mm diamond steel plate |
|
|
Brake chamber |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; Two pieces of 45L air tanks |
|
|
ABS |
Optional |
|
|
Twist Locks |
Four,Eight or Twelve pieces (Lifting type or Twist screw type) |
|
|
Valve |
WABCO valve (especial for exporting market ) |
|
|
Light |
LED light (especial for exporting market ) |
|
|
Voltage |
24V |
|
|
Receptacle |
7 ways (7 wire harness) |
|
|
Tool box |
One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
|
|
Painting |
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
|
|
Shipping Terms: |
By bulk cargo carrier, RORO or 40HQ container. |
|
