CIMC Chinese top brand with top quality
Certificate:CCC, ISO
| Dimension(mm) | L*W*H: 12500X2500X1500(mm) |
| Axle space(mm) | 6950mm+1310mm+1310mm |
| Tare weight(kg) | 8500kgs |
| Payload (kg) | 50000kgs |
| G.V.W.R. | 58800kgs |
| Landing gear | Linkage type, two speed with sand shoe |
| Kingpin | 3.5"Welded type |
| Suspension | Strengthened suspension for Africa area |
| Axle | FUWA axle, 13 ton capacity/set, 2pcs |
| Tire | 12.00R20 Radial tyre , 8 Pcs, |
| Rim | 8.5-20 ,12 Pcs |
| Twist lock | 12 units |
| Tool box | 1 unit |
| Spare tire carrier | 2 units |
| Main beam | 500,14/6/16 |
| Side beam | 16# channel steel ,160mm height |
| Floor | 3mm checked plate |
| Lights, electrical, accesories | yes, 24 volts, |
