| Type | Tractor Truck | |||
| Traction Type | 6x4 | |||
| Model | SX4254NV2941 | |||
| Brand | SHACMAN | |||
| Driving type | LHD option RHD | |||
| Cabin | F2000 lengthen high cabin,two sleeper, air heater | |||
| Engine | Brand | WEICHAI | ||
| Model | WD12.420 EUR2 | |||
| Power | 420hp | |||
| Type |
Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter cooling |
|||
| Displacement | 11.596liters | |||
| Max Output | 309kw | |||
| Max torque | 1750NM@1300-1600rpm | |||
| Gear box | 12JS180T | |||
| Clutch | 430 diaphragm type | |||
| Steering | ZF technology | |||
| Axle | front | 7.5t MAN | ||
| rear | 13t STR, double reduction drive axle ration:4.42 | |||
| Tyre | 12.00-20 | |||
| Frame(mm) | 780×243×(8+5) | |||
| Fuel tank capacity (L) | 380 | |||
| Max. Speed (km/h) | 92 | |||
| Kerb Mass | 9100kg | |||
| Total mass | 25000kg | |||
| Wheel base(mm) | 2925+1350 | |||
| Front overhang (mm) | 1525 | |||
| Rear overhang (mm) | 845 | |||
| Front track (mm) | 2036 | |||
| Rear track(mm) | 1800 | |||
| Approach angle | 18degree | |||
| Departure angle | 66degree | |||
| Dimension of box(mm) | 6600x2470x3710 | |||
