CIMC 3 Axles Van & Container Semi Trailer

Model NO.: CIMC
Certification: ISO9001
Tread: 2240mm
Independent Suspension Type: Cross Arm Type
Axle Number: 3
ABS Anti-lock Braking System: ABS Anti-lock Braking System
Condition: New
Wheelbase: 7460+1310+1310mm
Suspension: Leaf Spring 10/10/10
Outrigger: Jost 28 Tons
Specification: Standard
HS Code: 8716100000
Load Capacity: 50T
Wheel Base: 8000-9000mm
Grade: Heavy Duty
Shape: Van-type
Self-dumping: Not Self-dumping
Material: Steel
Overall Dimension: 13000*2550*2400mmmm
King Pin: 90#(3.5 Inch)
Axle: 3 Axles,Fuwa Axle
Trademark: CIMC
Origin: Shandong, China

Detail

semi trailer

1.CIMC 50ton cargo Semi Trailer for sale

2.1 40feet or 2 20feet container transportation

3.High quality and competitive price

4.All Kinds Of Design

5.Best after-sales

Product Description

MODEL	CIMC	Van freight semitrailer
Axle	3-axle	13ton FUWA
Suspension	Leaf spring (Fuwa brand)	10/10/10
Outrigger	JOSTA400T	28T
Trailer pin	50mm(2 inch)	Jost brand
Tire	11.00R20-16PR Radial tire	12pieces
Rim	8.0-20	12pieces
Relay valve	Standard
Brake system	ABS	4S/2M
Fasten System	No.24, (No.12 each side)
Accessories	One standard tool box	1000x500x500mm
External dimension (LWH) mm	13000mmx2550mmx2400mm
Wheel base	7460+1310+1310mm
Floor and side	Floor 3mm, side 1.5mm steel sheet
Main beam	Top Flange 14mm, Bottom Flange 16mm, Middle Flange 8mm.
Back door	1 pair
Twist Lock	12 nos. of ISO twist lock for 20ft container, 40ft container, 40HQ.
Tare weight	7500kg
Rated payload	50000kg
Max.payload	60000kg
Color	Red,Blue,Yellow,White	Other color can be optional
