Kg
Working mass, Kg

1600

(/)Kg
Distributed mass of vibrating drum (front wheel/rear wheel), Kg

800/800

(/)N/cm
Static linear load (front wheel/rear wheel), N/cm

88/88

km/h
Speed scope, km/h

0~9

%
Theoretical gradeability, %

30

mm
Minimum turning external radius, mm

2700

mm
Minimum ground clearance, mm

250

mm
Wheel base, mm

1350

Steering angle

±34°

Swing angle

±7°

Hz
Vibration frequency, Hz

70

mm
Nominal amplitude, mm

0.4

kN
Exciting force kN

17

mm
Diameter of compacting roller, mm

582

mm
Width of compacting roller, mm

893

Engine model

Perkins 403D-11

r/min
Engine rated speed, r/min

2600

kW
Engine rated power, kW

17.3

g/kW.h
Engine oil consumption, g/kW.h

253

L
Capacity of hydraulic oil tank, L

19

L
Capacity of fuel tank, L

24

L
Capacity of watering tank, L

110
