20000L BLOW MOLDING MACHINE
Detail

One Layer

10000L

20000L

Kayak

Machine

Custom-Made

Basic

Parameter

Capacity Range

1tr.

2000-10000

5000-20000





Machine Dimension(L*W*H)

m

15*9*11

16*9*13

9*6.5*10



Total Power

kw

600

780

360



Average Poser Consumption

kw

390

480

250



Accu-Head

Head Capacity

kg

300

750

60



Heating Power

kw

100

120

60



Clamping

  Unit

Clamping Force

kn

6000

8000

2800



Mould Platen Size (W*H)

mm

3000*3800

3600*4000

1600*4500



Distance Between Platen

mm

2200-5200

2200-6200

900*3000



Extrude

System

Screw Diameter

mm

150

180

120



Screw L/D Ratio



33/1

33/1

30/1



Plasticizing Capacity

Kg/hr.

1200

1600

600



Screw Speed

rpm.

10-50

10-50

10-50



Two Layers

10000L

20000L

Kayak

Machine

Custom-Made

Basic

Parameter

Capacity Range

1tr.

2000-10000

5000-20000





Machine Dimension(L*W*H)

m

15*9*11

16*9*13





Total Power

kw

650

780





Average Poser Consumption

kw

390

480





Accu-Head

Head Capacity

kg

300

750





Heating Power

kw

140

2000





Clamping

  Unit

Clamping Force

kn

6000

8000





Mould Platen Size (W*H)

mm

3000*3800

3600*4000





Distance Between Platen

mm

2200-5200

2200-6200





Extrude

System

Screw Diameter

mm

150*2

180*2





Screw L/D Ratio



33/1

33/1





Plasticizing Capacity

Kg/hr.

1200

1600





Screw Speed

rpm.

10-60

10-60





Three Layers

10000L

20000L

Kayak

Machine

Custom-Made

Basic

Parameter

Capacity Range

1tr.

2000-10000

5000-20000





Machine Dimension(L*W*H)

m

15*9*11

16*9*13





Total Power

kw

730

880





Average Poser Consumption

kw

420

420





Accu-Head

Head Capacity

kg

300

250





Heating Power

kw

150

250





Clamping

  Unit

Clamping Force

kn

6000

8000





Mould Platen Size (W*H)

mm

3000*3800

3600*4000





Distance Between Platen

mm

2200-5200

2200-6200





Extrude

System

Screw Diameter

mm

130*3

150*3





Screw L/D Ratio



33/1

33/1





Plasticizing Capacity

Kg/hr.

1200

1500





Screw Speed

rpm.

10-60

10-60
