ltem |
Specifications |
unit |
|
|
Rated load |
1400 |
kg |
|
|
Rated bucket capacity |
0.75 |
m³ |
|
|
Machine weight |
5000 |
kg |
|
|
Dumping height(from ground to main blade plate) |
3000 |
mm |
|
|
Dumping distance(from the front wheel to main blade plate) |
950 |
mm |
|
|
wheel base |
2250 |
mm |
|
|
Tread |
1500 |
mm |
|
|
Maximum breakout force |
44 |
KN |
|
|
Hinge-axis height at lifting limit |
3600 |
mm |
|
|
lifting time of swing arm |
5 |
s |
|
|
Total cycling time |
9.5 |
s |
|
|
Minimum turning radius(outer edge of bucket) |
4360 |
mm |
|
|
Articulated angle |
35 |
° |
|
|
Gradeability |
25 |
° |
|
|
tire size |
16/70-16 |
|
|
|
Overall demension of machine(L×W×H) |
5810*2060*2815 |
|
|
|
Engine model |
YN4C075-30CR |
|
|
|
Rated power/rotate speed |
55/2400 |
kW/rpm |
|
|
Travel speed |
Gear I(F/R) |
8 |
km/h |
|
Gear II(F) |
20 |
km/h |
|
